Copper Cables
Copper Cables
The expertise of our organization lies in designing Copper Cables. We are a reliable Copper Cables Manufacturer and Supplier in Roorkee, Uttarakhand. The Copper Cables that we offer are fabricated from the finest materials utilizing the latest technology. We manufacture Copper Cables as per the industry specified norms and standards. The Copper Cables can be availed from us in different specifications. Additionally, we also undertake specifications to customize Copper Cables as per clients requirements.
Availability
'SHALABH' Poly Vinyl Chloride Poly Vinyl Chloride (PVC) Insulated Twisted single Core Copper Conductor Wire 1100 Volts Grade Conforming to IS: 694 suitable or domestic Industrial purpose.
Attributes
- ISI Certified
- FIA, TAC Approved
- Fire Retardant
- Perfect Double Polyvinyl Chloride (PVC) Insulation
- Lowest Electricity Consumption
- Ease of Wiring
| Nominal Cross Sectional Area of Conductor (mm) | Number/Diameter of Wires (mm ) | Thickness of Insulation (Nom) (mm) | Overall Diameter (Approx. 9mm) | Current Carrying Capacity (A) | Resistance (Max) Per Km at 20°C Ohms) |
|---|---|---|---|---|---|
| 0.5 | 16/0.2 | 0.6 | 2.2 | 4 | 39 |
| 0.75 | 24/0.2 | 0.7 | 2.5 | 7 | 26 |
| 1.0 | 14/0.2 | 0.7 | 2.8 | 11 | 18.84 |
| 1.5 | 22/0.3 | 0.7 | 3.1 | 13 | 12.20 |
| 2.5 | 36/0.3 | 0.8 | 3.8 | 18 | 7.41 |
| 4.0 | 56/0.3 | 0.8 | 4.4 | 24 | 4.95 |
| 6.0 | 85/0.3 | 0.8 | 5.3 | 31 | 3.30 |
| 10 | 140/0.3 | 1.0 | 6.6 | 42 | 1.91 |
