Copper Cables

HR-FRLS-H PVC INSULATED SINGLE CORE UNSHEATED MULTISTRAND CABLE COPPER CONDUCTOR WIRE 1100 VOLTS GRADE

(CONFIRMING TO IS-694)

No. & DIA (MM)	Current Rating (AMPS.)	Price Per Coil (90 mtr.)
24/0.2 (0.75 sq mm)	8	1410
32/0.2 (1.00 sq mm)	13	1895
30/0.25 (1.50 sq mm)	18	2765
50/0.25 (2.50 sq mm)	24	4455
56/.30 (4.00 sq mm)	32	6575
84/.30 (6.00 sq mm)	41	9970
140/0.3 (10.00 sq mm)	51	17765
226/0.3 (16.00 sq mm)	58	27750

FR PVC INSULATED SINGLE CORE UNSHEATED MULTISTRAND CABLE COPPER CONDUCTOR WIRE 1100 VOLTS GRADE

(CONFIRMING TO IS-694)

No. & DIA (MM)	Current Rating (AMPS.)	Price Per Coil (90 mtr.)
24/0.2 (0.75 sq mm)	7	1365
32/0.2 (1.00 sq mm)	13	1810
30/0.25 (1.50 sq mm)	18	2665
50/0.25 (2.50 sq mm)	24	4235
56/.30 (4.00 sq mm)	32	6280
84/.30 (6.00 sq mm)	41	9530
140/0.3 (10.00 sq mm)	51	16970
226/0.3 (16.00 sq mm)	58	26420
